Cable Chain Making Machine


Product

Features
  • An automatic machine with high production capacity for manufacturing various types of chains.
  • It has a speed of 350 links/grains per minute.
  • guarantees precision, regularity, and cost-effectiveness in the production cycle.
  • The wire processing is compatible with a maximum size of 0.4 millimeters.
  • It is equipped with a cutting unit with adjustable height and a chain density sensor.
  • The chain density sensor, electronic speed controller with brake, electronic wire tension, and lamp are included.

Category: Chain Machines

Description

Automatic machine with high production capacity for cable chains with side-cut at a speed of 350 links per minute. This new version stands out for the threading that occurs once on the right and once on the left, thus avoiding the use of the chain collecting plate. The cable chain with side-cut is particularly suitable for combining with Bismark machines with several rows, avoiding powder welding, which is necessary with traditional chains, thus hugely benefitting fineness guarantee, regularity of the chain pitch and savings on the production cycle. By simply changing some parts, it can be adapted to process wires up to a maximum size of 0.4 mm. The machine is equipped with the height-adjustable cutting unit, the chain density sensor, the electronic speed regulator with brake, the electronic wire tensioner, and service lamp.

Cable Chain Making Machine

Specification

Workable wire

0,25-0,40mm

Max speed

450a/min

Lubrication

Automatic

Power supply

230V,50-60Hz,1ph

Absorbed power

0,3Kw

Pneumatic supply

5/6Bar

Air consumption

25nl/min

Dimensions

47x75x55cm

Weight

75kg

--

Optional

--

Steel painted base

--

Microscope support

--

Automatic chain skein winder
